♦ About Embstar ♦

—————————————————————————————————————————————————————————————————————————————————————————————————————————————



Shenzhen Embstar Technology Co., Ltd.

is mainly committed to research and development, production and sales of 3G/4G module,

WiFi module, Zigbee module, embedded system solutions and other products.

It is a high-tech enterprise that provides the development, production and sales services of embedded software and hardware product to the global market.



With a high-quality, high-level, innovative professional and technical team and management team, we constantly explore and innovate, strive to make progress in practice. In addition, we provide high-performance and high-reliability electronic product solutions with a complete and scientific quality management system so as to reduce production costs for customers and shorten the market cycle of products. Therefore, the company takes its good faith, strength and product quality to gain recognition of the industry.

  READ MORE>>>



Custom Service

—————————————————————————————————————————————————————————————————————————————————————————————————————————————



WiFi Module Solution

AR9341

WiFi Module Solution

QCA9531

WiFi Module Solution

AR9331

WiFi Module Solution

IPQ4018

WiFi Module Solution

QCA9563

WiFi Module Solution

MT7620A



♦ Star Products ♦

—————————————————————————————————————————————————————————————————————————————————————————————————————————————





OpenWrt QCA9531 chipset WiFi Module M16

  QCA9531 WiFi Module Size 48.4mm x 26mm x 9.0mm

  Compliant to 802.11 b/g/n

  DDR Memory up to 128MB

  SPI NOR Flash memory up to 32MB

  4 LAN ports and 1 WAN port

  Supports USB 2.0 host/device(option) mode

  Supports GPIO/LED

  Supports AP mode and Client mode

  Support High-Speed UART for console

  The MIPS R24k supports 64KByte I-Cache and 32Kbyte D-Cache,targeted to operate at up to 550MHz.

  Security: WPA/WPA2, WEP, TKIP and AES, WPS2.0, WAPI

Read More>>>



OpenWrt AR9331 chipset WiFi Module M03

  AR9331 WiFi Module Size 45mm x 24.7mm x 9.0mm

 Compliant to 802.11 b/g/n

 DDR Memory up to 512Mbit(64MB)

 SPI NOR Flash memory up to 128Mbit(16MB)

 4 LAN ports and 1 WAN port

 I2S audio interface

 Supports USB 2.0 host/device(option) mode

 Supports GPIO/LED

 Supports AP mode and Client mode

 Support High-Speed UART for console

 MIPS 24K process or operating at up to 400 Mhz

 Security: WPA/WPA2, WEP, TKIP and AES, WPS2.0, WAPI



Read More>>>



OpenWrt QCA9531+QCA9887 chipset WiFi Module

M31

  QCA9531+QCA9887 WiFi Module / Router Module Size 50mm x 30mm x 9.0mm

  Compliant to 802.11 a/b/g/n/ac

  DDR Memory up to 128MB

  SPI NOR Flash memory up to 32MB

    ■  LAN ports and 1 WAN port

    ■  Supports USB 2.0 host/device(option) mode

    ■  Supports GPIO/LED

    ■  Supports AP mode and Client mode

    ■  Support High-Speed UART for console

    ■  The MIPS R24k supports 64KByte I-Cache and 32Kbyte D-Cache, targeted to operate at up to 550MHz.

    ■  Security: WPA/WPA2, WEP, TKIP and AES, WPS2.0, WAPI



Read More>>>



OpenWrt QCA9563 chipset WiFi Module M63

QCA9563 WiFi Module Size 60mm x 40mm x 12mm

 Compliant to 802.11 b/g/n

 DDR Memory up to 128MB

 SPI NOR Flash memory up to 32MB

 SGMII Signal

 Supports USB 2.0 host/device(option) mode

 Supports GPIO/LED

 Supports AP mode and Client mode

 Support High-Speed UART for console

 The MIPS R24k supports 64KByte I-Cache and 32Kbyte D-Cache,targeted to operate at up to 775MHz.

 Security: WPA/WPA2, WEP, TKIP and AES, WPS2.0, WAPI



Read More>>>



nRF51822 chipset Bluetooth Module HLX-BLE-18

nRF51822 Bluetooth Module Size 20mm x 15mm x 2.0mm

 Compliant to BLE 4.0

  A button battery can work for more than half a year

Customizable functions according to customer’s demand

  It reserved 4 GPIO for customization

  As a slave, canslave, can transmit data through Bluetooth

  As a host, can network 8 slave Bluetooth

devices and realize master-slave communication ( 1 drag 8)



Read More>>>

Supporting Professional

WiFi Module Development Kits

 WiFi Module Development Kits

■  Easy test for functions of pin wifi module

■  Simple and has suitable precision testing

■  Fit for performance testing

Read More>>>
